RF4 RF-S02 360° Universal Rotating PCB Fixture
The RF4 RF-S02 is a professional-grade, 360-degree rotating PCB fixture designed for the most demanding micro-soldering tasks. Engineered with a heavy-duty magnetic base and high-temperature resistant synthetic stone, it allows technicians to rotate a motherboard to any specific angle without unmounting it. This flexibility is essential for precision jumper wire work, BGA reballing, and chip-level diagnostics on iPhone and Android devices, ensuring total stability and a shadow-free view under th
In stock
Delivery: 1-3 Days
Description
Unmatched Versatility for Complex Motherboard RepairPrecision is impossible without stability. The RF4 RF-S02 provides a specialized mechanical solution for holding irregularly shaped logic boards, allowing you to access every side of a component with a simple flick of the wrist.Key Features:360-Degree Infinite Rotation: The high-precision bearing system allows for smooth, continuous rotation. You can lock the board at the exact angle needed to follow a trace or align a BGA chip perfectly.Universal Multi-Point Clamping: Designed to securely grip everything from tiny Wi-Fi modules to large tablet motherboards. The adjustable jaws are shaped to hold boards by the edges, leaving the center areas clear for hot air and soldering work.Strong Magnetic Base Integration: The fixture is equipped with powerful magnets that lock onto any steel work surface or the RF4 integrated workstation base, preventing the jig from sliding during high-pressure tweezers or iron work.Heat-Resistant Synthetic Stone: The clamping blocks are made from high-density synthetic stone, which withstands direct heat from hot air stations ($400°\text{C}+$) without deforming or transferring heat away from the solder joint.Low-Profile Ergonomic Design: Specifically height-optimized for use under trinocular microscopes, ensuring you maintain a comfortable working distance and clear line of sight.Aviation-Grade Aluminum Alloy: The main body is CNC-machined from premium aluminum, providing a rust-proof, durable finish that stands up to the rigors of a high-volume GSM repair shop.Tool-Free Adjustment: Features intuitive knurled knobs for quick clamping and releasing, significantly speeding up the workflow for busy technicians.Technical Specifications:Brand: RF4Model: RF-S02 (Rotating Series)Rotation Angle: $360°$ HorizontalMaterial: Aluminum Alloy + Synthetic StoneBase: Magnetic High-Stability BaseApplication: PCB Soldering, IC Desoldering, Jumper Wire Work, Microscope Inspection.
